Add to cable management: flip terminations/interfaces, Disconnected, locations (of ends or cable) #2624

New Issue
Closed
opened 2025-12-29 18:20:37 +01:00 by adam · 1 comment
adam commented 2025-12-29 18:20:37 +01:00
Owner
Copy Link

Originally created by @Jackbennett on GitHub (May 21, 2019).

Environment

  • image: netboxcommunity/netbox:${VERSION-latest}

Proposed Functionality

  • Support to flip cable connection A/B termination sides
  • Support to flip interface A/B Sides
  • Support "Disconnected" cable Termination A or B
    • Show Status "Disconnected" in addition to "Connected" or "planned"
    • Support Termination Location if disconnected.
  • Support inventoried cables? That being disconnected A and B
    • Support Setting Termination Locations to the same location if both are disconnected, i.e. storage.
  • Support an inventory location that isn't a device.

Use Case

  • Personally I'd like all my cables terminations from one device to all be on the same side to make it easier to read. i.e Termination A being the switch device, Termination B being the server device.

  • You can connect a cables B->A but the interface A->B just makes following details a little clunky, See screenshots

  • When documenting an existing rack, for some reason I have cables in a switch port, that route to another rack and have been left dangling.

    • Of course change the status to reflect an obvious termination state. As there's no device location.
    • Termination in rack A device xyz would be nice to see it's Disconnected in Rack B

  • Given Termination A and B as disconnected, could there be a quick button to set both locations to the same value.

    • Some cables I don't care about, like I'll just reliable any old ethernet patch. But our direct attach SFP+ cables still exist and are always labelled, even in the store room. If both ends are disconnected could I set the cables location to storage shelves inventory item? Something like that.

  • Maybe just a location and ID field and add an inventory item list to it, pretty much almost like the device inventory tab.

Related I found #3145 for deprecated cables. I see reversing cables #2700 has come up, but didn't mention the use case when trying to scan through the connection list is a tiny bit less easy and doesn't match interfaces (screenshot):


While writing this I've found #2994. Perhaps this is what a can of worms looks like.


Also note in the screenshot is my cobbled together "Not Connected" Device assigned to no rack but I have to make each interface before assigning the cable.

It seems odd to me to delete a cable, it introduces a chance of re-entering a label incorrectly, It also keeps a history of cable connections attached to the label to identify a bad cable over time.

If I had cables routed through the building floors but not connected to anything, they still exist. If they used to be used for X but no longer, that's useful information.

On reflection does netbox have no concept of patch panels? If I add a panel as a device, labeling the interface, and the link into the switch interface, the "interface connections" page isn't going to abstract away that device to device path? I might as well look at the cables connection page anyway.

I'm still evaluating/setting up netbox, so I apologize if there's a stupid question.

Database Changes

  • Adds location (Rack) to cable termination
  • Add Inventory locations to group inventory items not in a device

I realise this is dangerously close to inventory tracking in general, so maybe not all of these bulleted points are appropriate. I don't think it's too out there or unreasonable.

Originally created by @Jackbennett on GitHub (May 21, 2019). <!-- NOTE: This form is only for proposing specific new features or enhancements. If you have a general idea or question, please post to our mailing list instead of opening an issue: https://groups.google.com/forum/#!forum/netbox-discuss NOTE: Due to an excessive backlog of feature requests, we are not currently accepting any proposals which significantly extend NetBox's feature scope. Please describe the environment in which you are running NetBox. Be sure that you are running an unmodified instance of the latest stable release before submitting a bug report. --> ### Environment * image: netboxcommunity/netbox:${VERSION-latest} <!-- Describe in detail the new functionality you are proposing. Include any specific changes to work flows, data models, or the user interface. --> ### Proposed Functionality * Support to flip cable connection A/B termination sides * Support to flip interface A/B Sides * Support "Disconnected" cable Termination A **or** B * Show Status "Disconnected" in addition to "Connected" or "planned" * Support Termination Location if disconnected. * Support inventoried cables? That being disconnected A **and** B * Support Setting Termination Locations to the same location if both are disconnected, i.e. storage. * Support an inventory location that isn't a device. <!-- Convey an example use case for your proposed feature. Write from the perspective of a NetBox user who would benefit from the proposed functionality and describe how. ---> ### Use Case * Personally I'd like all my cables terminations from one device to all be on the same side to make it easier to read. i.e Termination A being the switch device, Termination B being the server device. * You can connect a cables B->A but the interface A->B just makes following details a little clunky, See screenshots * When documenting an existing rack, for some reason I have cables in a switch port, that route to another rack and have been left dangling. * Of course change the status to reflect an obvious termination state. As there's no device location. * Termination in rack A device xyz would be nice to see it's Disconnected in Rack B * Given Termination A and B as disconnected, could there be a quick button to set both locations to the same value. * Some cables I don't care about, like I'll just reliable any old ethernet patch. But our direct attach SFP+ cables still exist and are always labelled, even in the store room. If both ends are disconnected could I set the cables location to storage shelves inventory item? Something like that. * Maybe just a location and ID field and add an inventory item list to it, pretty much almost like the device inventory tab. Related I found #3145 for deprecated cables. I see reversing cables #2700 has come up, but didn't mention the use case when trying to scan through the connection list is a tiny bit less easy and doesn't match interfaces (screenshot): ![image](https://user-images.githubusercontent.com/791134/58109748-182fef80-7be6-11e9-96b3-35e273e29d43.png) While writing this I've found #2994. Perhaps this is what a can of worms looks like. ![image](https://user-images.githubusercontent.com/791134/58110118-cfc50180-7be6-11e9-94cd-355000036b68.png) Also note in the screenshot is my cobbled together "Not Connected" Device assigned to no rack but I have to make each interface before assigning the cable. It seems odd to me to delete a cable, it introduces a chance of re-entering a label incorrectly, It also keeps a history of cable connections attached to the label to identify a bad cable over time. If I had cables routed through the building floors but not connected to anything, they still exist. If they used to be used for X but no longer, that's useful information. On reflection does netbox have no concept of patch panels? If I add a panel as a device, labeling the interface, and the link into the switch interface, the "interface connections" page isn't going to abstract away that device to device path? I might as well look at the cables connection page anyway. I'm still evaluating/setting up netbox, so I apologize if there's a stupid question. <!-- Note any changes to the database schema necessary to support the new feature. For example, does the proposal require adding a new model or field? (Not all new features require database changes.) ---> ### Database Changes * Adds location (Rack) to cable termination * Add Inventory locations to group inventory items not in a device <!-- List any new dependencies on external libraries or services that this new feature would introduce. For example, does the proposal require the installation of a new Python package? (Not all new features introduce new dependencies.) --> I realise this is dangerously close to inventory tracking in general, so maybe not all of these bulleted points are appropriate. I don't think it's too out there or unreasonable.
adam closed this issue 2025-12-29 18:20:38 +01:00
adam commented 2025-12-29 18:20:39 +01:00
Author
Owner
Copy Link

@jeremystretch commented on GitHub (May 21, 2019):

Inventory for cables and other consumables is out of scope for NetBox.

Additionally, please note that the A/B sides are intended to be completely interchangeable: There is no significance to which end is connected to which termination point.

@jeremystretch commented on GitHub (May 21, 2019): Inventory for cables and other consumables is out of scope for NetBox. Additionally, please note that the A/B sides are intended to be completely interchangeable: There is no significance to which end is connected to which termination point.
